Sunscape Air
Sunscape Pro
| Feature | Sunscape Air | Sunscape Pro |
|---|---|---|
| Power | 30W | 60W |
| Series Positioning | Silent & Minimalist | High-Performance Flagship |
| External Diameter | 90 mm | 90 mm |
| Height | 90 mm | 120 mm |
| Max Drive Current | 700mA | 700mA |
| Light Engine | 13-Pin High-Density COB | 13-Pin High-Density COB |
| Dimming Channels | 12-Channel PWM Matrix | 12-Channel PWM Matrix |
| Dimming Depth | 0.01% - 100% (1/10000) | 0.01% - 100% (1/10000) |
| Core Controller | ESP32-S3-WROOM-1U | ESP32-S3-WROOM-1U |
| Input Voltage | 48V DC | 48V DC |
| Thermal Protection | Active Fan + Onboard NTC | Active Fan + Onboard NTC |
HARDWARE ARCHITECTURE
Aerospace-Grade Architecture
A proprietary 68mm circular PCB design with 13-pin routing, specifically engineered for high-density COB arrays.
Dual-Stage Buck Logic
Advanced 48V-to-12V-to-3.3V power conversion ensures maximum stability for both logic circuits and cooling fans.
ESP32-S3 Intelligence
Driven by the ESP32-S3-WROOM-1U chip with an external IPEX antenna for rock-solid connectivity through metal housing.
Precise Thermal Management
Onboard NTC thermistors linked directly to the MCU for real-time temperature monitoring and intelligent fan control.
